Industrial-Grade IR Touch Frames
—Built for harsh environments
Product Advantages
FCC & CE certified
Operating -20°C to 65°C · storage -30°C to 85°C · humidity 10–90% non-condensing.
ESD protection level 4
Contact discharge ±8kV, air discharge ±15kV (EN61000-4-2). Robust for industrial EMC.
EMS / EMI compliance
IEC61000-4-3 3V/m · EN55022 class B. Reliable in electrically noisy environments.
Explosion-proof touch
Even if the display glass shatters, the IR frame continues to register touches — maximum safety.
Industrial-grade features · waterproof & rugged
F-Series waterproof option
Special waterproof structure for F-Series: top and bottom PCBA connections are fully sealed, making the frame resistant to moisture and splash water. Ideal for humid industrial sites or semi-outdoor kiosks.
All series industrial ready
- Operating temp: -20°C to 65°C (all E/K/F)
- Storage temp: -30°C to 85°C
- ESD / EMC: Level 4, 8kV/15kV, EMI Class B
- Explosion proof: Glass breakage does not stop touch
All E-Series, K-Series and F-Series share these industrial ratings. Waterproof modification only applies to F-Series (order as option).
Product series
Industrial specifications & applications
E-Series · custom
| Accuracy | < ±1mm |
| Touch points | 10–32 simultaneous |
| Response | <10ms |
| Max size | 500″ (12m) |
| Sunlight | 10k LUX, shielded |
| Architecture | Modular PCBA, QC-SUSB |
| Industrial | -20°C~65°C, ESD level 4 |
Applications
View Product →K-Series · LED specialist
| Accuracy | < ±1mm |
| Touch points | 20 simultaneous |
| Response | <6ms |
| Max size | 240″ (5m) |
| Bezel | 12mm (world’s narrowest) |
| Dual-host | Dual-USB, dynamic mapping |
| Industrial | -20°C~65°C, anti-interference |
Applications
View Product →F-Series · 27–110"
| Accuracy | < ±1mm |
| Touch points | 40-touch capability |
| Latency | <10ms |
| Sunlight | 10klux operation |
| Profile/Bezel | 10mm thin, 18mm bezel |
| Waterproof opt. | Sealed top/bottom (IP54) |
| Industrial | -20°C~65°C, 500k units |
Applications
View Product →Related Videos
F Series waterproof demo
Sealed frame working under dripping water — 5cm edge blind zone explained
Extreme Dust vs IR Touch Frame
See How Adaptive & Stable It Really Is
Explosion proof touch
Glass cracked but IR frame still registers every touch
Anti interference: IR + LED display noise
Patented filtering vs conventional IR
