Infrared Touch Frame
—1 to 100 points · industrial · anti‑explosion
Product Advantages
1‑100 touch points
Fully customizable touch point — from single‑touch to 100‑point. Works with both LED and LCD displays.
±1mm accuracy
High‑precision touch for demanding applications — smooth, responsive, and reliable.
Industrial & explosion‑proof
Rugged design, wide temperature range. Even if the display glass breaks, touch remains functional.
Extra large size up to 500"
Cost‑effective solutions for giant touch walls, video walls, and custom installations.
Widely used across industries
Where our IR frames excel
Commercial
Retail kiosks, digital signage, hotel self‑check-in
Education
Interactive whiteboards, classroom large‑format displays
Advertising
Touch advertising machines, interactive posters
Entertainment
Museum exhibits, video walls, gaming kiosks
Finance
Bank self‑service terminals, trading floor displays
Sports & Culture
Stadium interactive guides, cultural center touch tables
One touch frame family serves them all — choose E‑Series, K‑Series, or F‑Series according to your size and performance needs.
IR Touch Frame series
Technical specifications
E‑Series · custom up to 500"
| Accuracy | < ±1mm |
| Touch points | 10–32 simultaneous |
| Response | <10ms |
| Max size | 500″ (12m) |
| Sunlight | 10k LUX, shielded |
| Architecture | Modular PCBA, QC-SUSB |
| Compatibility | Win/macOS/Linux/Android, TUIO |
Applications
View Product →K‑Series · slim 12mm, up to 240"
| Accuracy | < ±1mm |
| Touch points | 20 simultaneous |
| Response | <6ms |
| Max size | 240″ (5m) |
| Bezel | 12mm (world’s narrowest) |
| Dual-host | Dual-USB, dynamic mapping |
| Anti-interference | LED noise filtering |
Applications
View Product →F‑Series · 27–110", 40‑touch
| Accuracy | < ±1mm |
| Touch points | 40-touch capability |
| Latency | <10ms |
| Sunlight | 10klux operation |
| Profile/Bezel | 10mm thin, 18mm bezel |
| Reliability | 500k+ units deployed |
| Glass overlay | 3mm tempered (optional) |
Applications
View Product →Who We Are
Built on 13 years of expertise
touchsmith
Committed to bringing large‑scale touch experience to every person, family and organization.
We build an efficient, dynamic and free touch world through competitive, stable products in digital signage, self‑service terminals, smart conference tablets, and digital exhibition halls.
- 13 years pioneering expertise
- Patented IR noise filtering (LED displays)
- SDK & TUIO — third‑party integration ready
- Plug‑and‑play: Win/Linux/Android/macOS
- QC‑SUSB dynamic mapping & diagnostic
- Open cooperation with ecological partners
Cross‑industry touch in action
Touchsmith’s 13-year journey
From 2012 to today – 500k frames deployed
How We Make High-Precision Touch Frames
Welding, QC Inspection, Assembly & Factory Testing
K Series: LED noise rejection
Patented filtering vs conventional IR on fine-pitch LED
Interactive museum wall
E Series on a 12m × 1.6m video wall in a cultural exhibition
